Monitor Audio C1M Creator Series In-Ceiling Speaker Single

Monitor Audio C1M Creator Series In-Ceiling Speaker Single

Introducing the medium-sized Tier 1 in-ceiling loudspeaker, a cutting-edge two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter. Tailored for cost-effective installations, this speaker prioritizes product simplicity and robust acoustic performance. With a 212 mm cut-out dimension, a revolutionary patented Quik-Link speaker cable connector, and the enhanced Tri-Grip II system, installation becomes quick, simple, and reliable. Experience the advantage of improved clarity, wider dispersion, and lifelike high-fidelity sound – delivering the quality expected from any Monitor Audio passive box loudspeaker. Choose from the optional square or premium grille to complement this exceptional model.

Key Features

• Ideal for cost-effective installations, where product simplicity and solid acoustic performance is required
• Two-way design
• 1 x 1" (25 mm) C-CAM tweeter with UD Waveguide I for lifelike sound
• 1 x 7" (178 mm) C-CAM mid-bass driver for clear mid-range and full bass
• Patented Quik-Link speaker cable connector for quicker installation
• Tri-Grip II for easy and secure fitment

General Information

• Enclosure Type: Open

• Guarantee Period (Months): 60

• Output: Mono

• Power Type: Passive

• Weight Each (Kg): 1.9


Application Appearance

• Visible Colour: White

• Visible Shape: Circular


Dimensions

• Cutout Diameter (mm): 212

• Mounting Depth (mm): 99

• Overall Depth (mm): 103

• Overall Diameter (mm): 242


Detailed Specifications

• Compatible Amplifier (Watts RMS): 35 - 130

• Frequency range (Hz): 35 - 30000

• Nominal Impedance (Ω): 8

• Max Power High (Watts): 65

• Sensitivity (dB): 86

• Sound Pressure (dB): 113


Driver Information

• Bass: 1
• Biggest Driver Size (mm): 178
• Tweeter: 1
